Map the room and equipment
Measure the usable floor area, doors and fixed obstacles. Mark equipment locations, heavy point loads and walkways. Tell the supplier if the project includes dropped weights or moving machines; a general foam mat should not be assumed to protect a subfloor from every load.
Calculate the tile layout
Use the installed tile dimensions to plan rows and columns. For a nominal 3 × 4 m rectangle with 60 cm tiles, a 5 × 7 grid needs 35 tiles before considering edge strips and cuts. This is an example, not a guaranteed package count for a particular model.
Prepare the substrate
Follow the model’s installation instructions and inspect the underlying floor for debris, moisture and irregularities. Confirm compatibility with existing floor finishes or heating systems when relevant. Assemble a sample area and check stability, seams and transitions before installing the complete layout.
Inspect during use
Review movement at joints, edge lift and wear around equipment. Follow approved cleaning instructions and inspect beneath removable tiles when needed. Keep matching spare tiles for damaged sections and confirm replacement compatibility with the supplier.
